| MODEL | STROKE MM | LINER SIZE MM | MAXIMUM WORKING PRESSURE KG/CM2 | NORMAL OPERATION AT 75 SPM | MAXIMUM RECOMM- ENDED AT 100 SPM | INPUT SPEED RPM | SUCTION SIZE MM | DELIVERY SIZE MM | WEIGHT KGS (APROXIMATE) | ||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| DISPLAC EMENT LPA | POWER BHP | DISPLACEMENT LPA | POWER BHP | NORMAL OPERATION | MAX OPERTATION | ||||||||
| MCD-125 (5*4 1/2) | 125 | 115 100 90 75 65 |
17.21 23.09 28.75 42.58 58.27 |
375 280 225 152 111 |
17.25 | 501 374 300 203 148 |
23 | 303.75 | 405 | 76.2 | 50.8 | 1025 | |
| MCD-150 LWF (6"*5") | 150 | 125 115 100 90 75 |
22.03 26.16 35 43.75 64.55 |
536 451 337 270 183 |
32 | 715 602 450 360 244 |
42 | 394 | 525 | 100 | 50.865 | 1550 | |
| MCD-150 LW (6"*6") | 150 | 150 140 125 115 100 90 75 |
15.16 17.46 22.03 26.16 35 43.75 64.55 |
779 676 536 451 337 270 183 |
32 | 1039 902 715 602 450 360 244 |
42 | 394 | 525 | 100 | 50.865 | 1550 | |
| MCD-150 STD (6"*6") | 150 | 150 140 125 115 100 |
15.16 17.46 22.03 26.92 36.41 |
765 663 523 438 324 |
32 | 1021 885 698 585 433 |
42 | 341.25 | 455 | 100 | 75 | 1700 | |
| MCD-150 (6"*6") | 150 140 125 115 100 |
20.74 23.84 30.24 36.06 48.79 |
765 663 523 438 324 |
43 | 1021 885 698 585 433 |
57 | 341.25 | 455 | 100 | 75 | 1700 | ||
| MCD-200 (8"*6") | 200 | 150 140 125 115 100 |
20.74 23.84 30.24 36.06 48.79 |
1020 885 697 585 432 |
57 | 1361 1180 930 780 577 |
75 | 341.25 | 455 | 125 | 100 | 2150 | |
| NORMAL OPERATION AT 60 SPM / MAXIMUM RECOMM ANDED AT 90 SPM | |||||||||||||
| MCD-200H LW (8"*7 1/2") | 200 | 190 175 165 150 140 125 |
16.91 20.01 22.59 27.51 31.77 40.29 |
1330 1124 996 817 708 558 |
60 | 1995 1685 1493 1226 1062 837 |
88.8 | 273 | 410 | 150 | 100 | 4215 | |
| MCD-250 (10"*6") | 250 | 150 140 125 115 100 90 75 |
27.51 31.77 40.26 48.07 64.95 81.75 123.89 |
1022 885 698 585 433 344 227 |
75 | 1533 1328 1047 878 650 516 341 |
111 | 314.4 | 471.6 | 100 | 75 | 3815 | |
| MCD-250H LW (10"*7 1/2") | 250 | 190 175 165 150 140 125 |
16.91 20.01 22.59 27.51 31.77 40.29 |
1663 1405 1245 1022 885 698 227 |
75 | 2494 2107 1867 1533 1328 1047 |
111 | 314.4 | 471.6 | 250 | 100 | 4515 | |
